PARTS LIST & ILLUSTRATION Section 8 - Pg 13
8.7 Above Deck – Compressor, Air Inlet and Parts
PART
KEY DESCRIPTION NUMBER QTY
1 Adapter, Swivel 1-1/2" 040292 1
2 Compressor, 2.56 Ratio
Standard Short Shaft 250187-301 1
2B Compressor, 3.95 Ratio
Standard Short Shaft 250187-303 1
2C Compressor, 3.04 Ratio
Standard Short Shaft 250187-312 1
2D Compressor, 3.95 Ratio
High Strength Short Shaft 250200-818 1
2E Compressor, 2.56 Ratio
High Strength Short Shaft 250202-291 1
3 Elbow, Sae O-Ring X Female Pipe Swivel 260105-009 1
4 Elbow, 1/4t X 1/8p Push-On 261309 2
5 Elbow, 90 Deg. Push On 1/4t X 1/4p 261310 2
6 Adapter, 1-1/2" Pipe X 1-1/2 O-Ring 261938-016 1
7 Tubing, Flex 3" Air Intake 262090 8.3
8 Clamp, Hose 3" 263714 2
9 Adapter, #4 Msae O-Ring X 1/8 Fnpt 263868-004 1
10 Valve, Inline Check 1/8p 264103 1
11 Bushing. 1/4 P X 1/8 P Extended 265437 1
12 Cover,Colored Push Loc Orange 269118-002 1
13 Cover,Colored Push Loc Red 269118-003 1
14 Cover,Colored Push Loc Yellow 269118-007 2
15 Filter, Air 8" Mh 3" Outlet 271043 1
16 Nipple, Pipe 1/8 X Close 822202-000 1
17 Elbow, 37fl/90m #04 X 1/8 860204-012 1
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE MACHINE SERIAL NUMBER
To Next Page
