3.5.3. Timing a CLOSE Operation
Follow the steps below to time a CLOSE operation:
a. Start from the “START-UP” menu:
Press the [1] key (TIME BRKR).
b. The following screen will be displayed
Press the [2] key (CLOSE).
c. The following screen will be displayed:
Manually close the breaker.
d. The following screen will be displayed:
Press the [1] key (YES) to print the test results on the unit’s built-in thermal printer.
PRINT TEST RESULTS?
1.YES
2.NO
TEST: CLOSE
CLOSE BREAKER NOW...
TIMING MODE:
1.OPEN
2.CLOSE
3.OPEN-CL 4.CL-OPEN
5. SP OPEN
1. TIME BRKR 05/14/12
2. GET RSLT 08:45:25
3. SETUP
4. DIAGNOSTICS
