3.5.5. Timing a CLOSE-OPEN Operation
Follow the steps below to time a CLOSE-OPEN operation:
a. Start from the “START-UP” menu:
Press the [1] key (TIME BRKR).
b. The following screen will be displayed:
Press the [4] key (CL-OPEN).
c. The following screen will be displayed:
Manually initiate a CLOSE-OPEN operation on the breaker.
d. The following screen will be displayed:
Press the [1] key (YES) to print the test results on the unit’s built-in thermal printer.
PRINT TEST RESULTS?
1.YES
2.NO
TEST: CLOSE-OPEN
CLOSE BREAKER NOW...
TIMING MODE:
1.OPEN 2.CLOSE
3.OPEN-CL
4.CL-OPEN
5. SP OPEN
1. TIME BRKR 05/15/12
2. GET RSLT 09:15:25
3. SETUP
4. DIAGNOSTICS
