VANNER
Incorporated
Owner’s Manual
300 Watt VLT Series Inverter Owner’s Manual - 5 -
3 Specifications and Features
3.1.1 Specifications
Model Number
SPECIFICATIONS
VLT12-300 VLT24-300
AC Power Output
Rated Continuous Output 300 Watts
Surge Rating 400 Watts
Output Waveform True Sine Wave
Total Harmonic Distortion 6% THD Typical
Output Voltage 110 VAC ± 5%
Output Frequency 60 Hz ± (0.3%)
AC Output Wiring Method
GFCI Duplex Receptacle
Maximum, Efficiency 89%
Power Factor Allowed cos -90º to +90º
DC Input Voltage
12V Nominal 24V Nominal
DC Input Voltage Range 11.5 to 16.0 23.0 to 32.0
Low DC voltage Shutdown / Restart 11.3 / 13.5 22.5 / 26.5
High DC voltage Shutdown / Restart 16.3 / 15.8 32.6 / 31.5
Inverter ON with no AC load Less than 35ma
Full load Approximately 35 DC Amps Approximately 18 DC Amps
System
Protection
Overload, Short Circuit, Reverse Polarity (internal non-
replaceable fuse), Over/Under Input Voltage, Over Temperature
Safety UL458
Remote Control ON/OFF Control by customer supplied external switch
Ambient Operating Temperature -13 to +105ºF (-25 +40ºC)
Storage Temperature -22 to 158ºF (-30 to +70ºC)
Fan Cooling Thermostatically controlled cooling fan
Enclosure Painted aluminum
Dimensions (L x W x H) 9.5” L x 6.1” W x 2.8” H
Weight 7.7 pounds
Note: Specifications are subject to change without notice.
