5
186
360
520
810
D
F
Steam Outlet 54 mm
Gland Plate
120 X 120
305
330
6
6
55
305
52
90
62
299
73555
165
165
70
For clearance around the unit for ventilation and access and for units with RDU’s see page 7
Covering model references:
LE30 – All
LE45 – All
Left:
View from beneath unit
showing-
‘F’ (Feed) ¾ “ BSP male
connection for connection
for flexible hose provided
with unit.
‘D’ (Drain) connection for
35 mm pipe.
Right:
View from beneath unit
showing the electrical gland
plate
(approx 120 mm x 120 mm)
with an entry hole
(approx 105 mm x 90 mm)
Left:
Top view of unit showing
steam outlet position
(54 mm spigot)
Below:
Rear view of unit showing
wall mounting points.
