Steam Outlets
54 mm
Gland Plate
120 X 120
Gland Plate
120 X 120
For clearance around the unit for ventilation and access see page 7
Covering model references:
LE60 – All
LE90 – All
LE110 – All
Left:
Top view of unit showing
steam outlet positions
(54 mm spigots)
Below:
Rear view of unit showing
wall mounting points.
Left:
View from beneath unit
showing-
‘F’ (Feed) ¾ “ BSP male
connection for connection
for flexible hose provided
with unit.
‘D’ (Drain) connection for
35 mm pipe.
Right:
View from beneath unit showing
the electrical gland plate
(approx 120 mm x 120 mm)
with an entry hole
(approx 105 mm x 90 mm)
