VARI❋LITE® - VL500™ WASH LUMINAIRE USER’S MANUAL
48 01-March-2006 02.9685.0001 0
DMX
DMX Data and
Pan/Tilt
Mode Extended Operates in
extended 16 bit mode
16 Bit Operates in standard
16 bit mode
8 Bit Operates in 8 bit mode
Easy Operates in a limited
mode
Data Chan XX DMX Channel XXXX Data
Pan/Tilt Pan/Tilt Options Swap Swap Pan & Tilt ON
OFF (default)
InvPan Invert Pan ON
OFF (default)
InvTilt Invert Tilt ON
OFF (default)
Fixture StatusStatus/Error Display Scrolls error messages *
or displays OK
Re-Cal Recalibrate OK?
Lum Id Luminaire ID XXXX. Luminaire ID Number
Version Software Version XX/XX/XX Version Date
Fixt Hrs Fixture Hours On
(powered)
XXXX Hours
Download Download Program to
Luminaires
OK?
Manual
Manual
Commands
Pan Pan Motor XXXX Data
Tilt Tilt Motor XXXX Data
Dimmer * Dimmer XXX Data
Diffuser Diffuser XXX Data
Cyan Cyan Color XXX Data
Yellow Yellow Color XXX Data
Magenta Magenta Color XXX Data
Table 4-1: Menu System Chart (Continued)
1st Level 2nd Level 3rd Level 4th Level 5thLevel
* = Inactive/Disabled when "External" Dimmer setting is selected.
