MENU SYSTEM : MENU OPERATION
4
02.9685.0001 0 01-March-2006 49
Test **
System Test
ALL SEQ Sequence Through All
Tests
RunTest Press [Menu] to stop tests
Pan/Tilt Pan/Tilt RunTest
Pan Pan Pan 1
Pan 2
Tilt Tilt Tilt 1
Tilt 2
Dimmer Dimmer Dimmer 1
Dimmer 2
Dimmer 3
Diffuser Diffuser Diffuser 1
Diffuser 2
Diffuser 3
Cyan Cyan Color System Cyan 1
Cyan 2
Cyan 3
Yellow Yellow Color System Yellow 1
Yellow 2
Yellow 3
Magenta Magenta Color System Magenta 1
Magenta 2
Magenta 3
Encoder Encoder (Allows hand
movement to check values)
Pan Value Displays encoder
value
Tilt Value Displays encoder
value
Fans Fans Test Value 1 (slow) to 7 (fastest)
Temp Temperature LVS Temp Low Voltage
Supply temperature
Value Displays
temperature in
o
C
MCB Temp Main Control
Board temperature
Value Displays
temperature in
o
C
** Refer to “Diagnostic Tests” on page 54 for more information.
Table 4-1: Menu System Chart (Continued)
1st Level 2nd Level 3rd Level 4th Level 5thLevel
