BDR-595D Adela
23
d) Fill the hub inside with new grease (e.g. for water pumps) lubricating at the same time
also the flange with balls and free wheel surfaces.
e) Slide the free wheel on the wheel axis. The pin driven into the wheel axis must lean
against the inclined surface on the free wheel (see Fig. 9). Put the wheel onto the axis,
screw the nut to the stop; then release it by one split pin groove and secure the connection
with a new split pin. The wheel must be freely turning with no great axial clearance.
f) Check of the correct free wheel assembly: Press the wheel drive clutch lever, turn the
driving wheel by hand in the direction of travel forward. The free wheel must be clicking.
6.9 Machine storage.
Prior to any longer storage, clean the machine from all dirt, debris and plant residues.
Repair damaged paint on machine parts.
For any long-time storage of the machine it is advisable:
a) to conserve blades on the mowing disk
b) to drain petrol out of engine fuel tank and from carburetter (more
instructions see Operating manual for engine use)
Access of unauthorized persons to the machine is to be prevented. Protect the machine
from weather impacts but don’t use air-tight protection due to a possibly increased corrosion
under it.
6.10 Disposal of packaging and machine after the end of service life.
After unpacking the machine, you are obliged to provide for the disposal of packaging
material with taking into account the use of secondary raw-materials according to Waste Law
