BDR-595D Adela
26
Machine casing
Pos.
Part Name Dimensions Drawing-Standard
Ord. No.
Pcs
1 Frame 22 9 1536 050 196 001
1
2 Screen holder 22 9 1856 005 169 016
1
3
4 Handle 22 9 8044 009 196 016
1
5 Upper cover 22 9 8545 034 196 049
1
6 Cutting disc cover
22 9 8549 016 196 050
1
7 Cover extension 32 0 8542 039 196 051
1
8 Mudflap 32 0 8530 036 189 115
1
9 Cover holder 32 0 1530 132 196 048
2
10
Mudflap pad 32 0 9230 010 182 010
1
11
Cover coupling 622 9 1540 010 196 507
1
12
Pillar 632 0 1520 051 196 527
1
13
14
Screen 632 0 1840 072 196 512
1
15
Left mudguard 632 0 8545 045 196 506
1
16
Right mudguard 632 0 8545 046 196 505
1
17
Lower cover 632 0 8545 068 196 549
1
18
Bolt M5x10 ČSN 02 1103.25 195 525
2
19
Bolt M6x16 ČSN 02 1103.25 189 552
5
20
Bolt M6x20 ČSN 02 1103.25 189 551
7
21
Bolt M8x16 ČSN 02 1103.25 106 547
4
22
23
Nut M6 ČSN 02 1492.25 168 516
15
24
Nut M8 ČSN 02 1492.25 104 622
1
25
Washer 6,4 ČSN 02 1702.15 189 571
14
26
Washer 8,4 ČSN 02 1702.15 131 517
1
27
Washer 6,6 ČSN 02 1727.15 169 508
10
28
Washer 5,5 ČSN 02 1729.25 195 531
2
29
30
31
Washer 8,2 ČSN 02 1740.05 104 574
4
32
Rosette M8x20 D.50 "JJZ"
EUROPLAST 171 525
1
33
Nut cap 034-03-M6 SUNAP Neratovice
169 505
2
34
Nut cap 034-03-M8 (13) SUNAP Neratovice
169 504
1
35
Square plug 20x20 SUNAP Neratovice
169 506
1
36
Cylindrical cap 14x70 red VINYL-FLEX 189 578
1
