Vari BDR-595 D Adela - Page 28

BDR-595D Adela
28
Handlebars
Pos.
Part Name Dimensions Drawing-Standard
Ord. No.
Pcs
1 Handlebars weldment 22 9 8078 059 196 002
1
2 Travel clutch lever 32 1 8058 009A 196 013
1
3 Cutting disk drive lever
32 1 8058 009B 196 067
1
4 Clutch bowden cable 622 9 8074 044 196 515
1
5 Pulley bowden cable 622 9 8074 045 196 516
1
6 Brake bowden cable 622 9 8074 046 196 517
1
7 Lever stop 632 0 8065 002 196 519
2
8 Lever pin 632 0 9311 157 196 520
2
9
10
Bolt M5x10 ČSN 02 1103.25 195 525
2
11
Bolt M8x50 ČSN 02 1319.25 189 593
2
12
Nut M6 ČSN 02 1401.25 1800141
3
13
Nut M5 ČSN 02 1492.25 105 518
2
14
Washer 8,4 ČSN 02 1702.15 131 517
2
15
Yoke ring 4 ČSN 02 2929.05 189 576
4
16
Washer 5,3 ČSN 021702.15 189 581
2
17
Plastic rosette M8-D.50 "JJW"
EUROPLAST 189 521
2
18
19
Rubber handle ART 773 black
195 518
2
20
Accelerator lever 1AT09007 32 1 8058 011 196 548
1
