Pcs
1 Brake shoe 22 9 1664 024 189 014 2
2 Driven pulley 22 9 3325 012 189 004 1
3 Upper disc 22 9 5025 011 196 056 1
4 Brake cam 22 9 8032 048 196 003 1
5 Pulley arm 32 0 3330 034 196 010 1
6 Driving disc holder 32 0 3821 017 189 058 1
7 Drive shaft 32 0 3822 022 196 005 1
8 Lower disc 32 0 5020 011 189 057 1
9 Blade 32 0 6030 009 189 060 4
10 Shim 42/36/0,1 32 0 9220 024 110 012 3
11
12 Spacing ring 32 0 9220 199 189 011 1
13 Cover 32 1 9220 126 127 014 1
14 Pulley 632 0 3325 040 189 586 1
15 Flange 632 0 3821 015 189 059 1
16 Washer 14 632 0 9220 205 189 061 4
17 Brake shoe pin 632 0 9311 152 196 524 1
18 Pulley bearing sleeve 632 0 9320 071 196 528 1
19 Brake shoe spring 632 0 9746 044 189 511 1
20 Spring TZ1,8x16,2x63x20 FEVOZ Slavičín 169 514 1
21 Spring T 080.088.0632 FEVOZ Slavičín 184 553 1
22 Bolt M6x14 ČSN 02 1151.25 189 557 6
23 Bolt M6x45 ČSN 02 1103.25 195 523 1
24 Bolt M6x30 ČSN 02 1103.25 184 552 1
25 Bolt M10x20 ČSN 02 1103.55 1512527 4
26 Nut M6 ČSN 02 1401.25 1800141 6
27 Nut M6 ČSN 02 1492.25 168 516 2
28 Nut M10 (OK16) ČSN 02 1403.25 111 503 4
29 Washer 6,4 ČSN 02 1702.15 189 571 4
30 Washer 8,4 ČSN 02 1702.15 131 517 1
31 Washer 10,5 ČSN 02 1702.15 131 518 4
32 Washer 21 ČSN 02 1702.15 124 530 1
33 Washer 6,1 ČSN 02 1740.05 6510920 6
34 Pin 5x40 ČSN 02 2156 196 502 1
35 Feather 5x5x25 ČSN 02 2562 189 574 1
36 Feather 6x6x25 ČSN 02 2562 169 503 1
37 Retaining ring 8 ČSN 02 2930 195 534 2
38 Retaining ring 10 ČSN 02 2930 6021519 1
39 Retaining ring 20 ČSN 02 2930 110 515 2
40 Retaining ring 35 ČSN 02 2931 126 503 1
41 Retaining ring 42 ČSN 02 2930 136 506 2
42 Bearing 6300 2RS ČSN 02 4630 189 585 1
43 Bearing 6004 2RS ČSN 02 4630 9943158 4
NOTE:
1) The machine is supplied with a barrel spanner No. 16 with handle.
2) A set of spare blades is supplied under a following mark:
