Vari BDR-595 D Adela - Page 32

BDR-595D Adela
32
Wheel drive
Pos.
Part Name Dimensions Drawing-Standard
Ord. No.
Pcs
1 Gearbox BDR-595 22 9 3282 052 196 014
1
2 Driving pulley 22 9 3325 032 196 046
1
3 Driven clutch element
32 0 3625 029B 196 045
1
4 Engine plate 22 9 8032 049 196 007
1
5 Feather 3/16" 32 0 3330 021 189 036
1
6 Bolt W 3/8" 32 0 9016 057 105 011
1
7 Cuff 632 0 1642 008 189 507
2
8 Free wheel 632 0 8021 026 196 509
2
9 Spring 632 0 9746 046 189 512
2
10
Wheel coupling spring
632 0 9746 056 196 518
1
11
Bolt M5x12 ČSN 02 1143.50 189 580
6
12
Bolt M8x16 ČSN 02 1103.25 106 547
4
13
Bolt M8x40 ČSN 02 1103.25 196 503
4
14
Nut M8 ČSN 02 1492.25 104 622
3
15
Nut M16x1,5 ČSN 02 1412.25 189 560
2
16
Washer 5,1 ČSN 02 1740.05 127 512
6
17
Washer 5,3 ČSN 02 1702.15 189 581
6
18
Washer 8,2 ČSN 02 1740.05 104 574
8
19
Washer 8,4 ČSN 02 1702.15 131 517
7
20
Washer 10,2 ČSN 02 1740.05 106 530
1
21
Washer 17 ČSN 02 1702.25 189 566
2
22
Cotter pin 4x32 ČSN 02 1781.05 189 577
2
23
Feather 4x4x18 ČSN 02 2562 196 508
1
24
Left wheel 3.00-8 EP-007 ET-91590 189 505
1
25
Right wheel 3.00-8 EP-007 ET-91590 189 506
1
26
V-belt X13x1300 Ld 6T6K
OPTIBELT 196 504
1
27
Engine HONDA GCV 160 171 535
1
28
Ball Diam. 7,144 189 575
4
29
Rubber element 632 0 9220 231 196 545
1
NOTE: for easy replacement the wheels are supplied with pressed-
on balls (pos. 28)
under mark as follows:
Left wheel 22 1 1770 024 189 042
1
Right wheel 22 1 1770 025 189 043
1
