Vari BDR-595 D Adela - Page 34

BDR-595D Adela
34
Gearbox
Pos.
Part Name Dimensions
Drawing-Standard
Ord. No.
Pcs
1 Fork weldment 22 1 3330 013A 189 078
1
2 Complete lever 22 9 3330 017 196 022
1
3 Complete driving disc
22 9 3616 006 189 029
1
4 Worm 2:54 32 0 3214 028 196 023
1
5 Worm wheel 32 0 3221 016 196 027
1
6 Shaft - Wheel axle 32 0 3814 008 189 028
1
7 Shim 20/14,2/0,2 32 0 9220 115 127 027
1
8 Shim 20/14,2/0,3 32 0 9220 114 127 026
1
9 Spacer ring 10,7 32 0 9220 195 189 032
1
10
Cup 32 0 9220 197 196 032
1
11
Plug 32 1 9016 036 106 050
2
12
Pinion 19 teeth 632 0 3014 010 196 530
1
13
Gear 51 teeth 632 0 3021 028 196 529
1
14
Cover 632 0 3253 044 196 511
1
15
Box 632 0 3253 045 196 510
1
16
Felt 632 0 9520 045 189 528
1
17
Spring 632 0 9746 047 189 527
1
18
Bolt M4x10 ČSN 02 1143.50 196 521
4
19
Pin 5x12 ČSN 02 2150 196 522
2
20
Pin 5x20 ČSN 02 2150 189 556
2
21
Pin 10x45 ČSN 02 2150 2010260
2
22
Retaining ring 12 ČSN 02 2930 6021502
2
23
Retaining ring 14 ČSN 02 2930 110 513
1
24
Retaining ring 17 ČSN 02 2930 110 514
1
25
Retaining ring 28 ČSN 02 2930 189 553
1
26
Retaining ring 47 ČSN 02 2931 126 504
2
27
Bearing 3203 ČSN 02 4630 196 533
1
28
Bearing 6005 ČSN 02 4630 129 535
2
29
Bearing 6202 ČSN 02 4630 9943131
1
30
Bearing 6203 ČSN 02 4630 106 507
1
31
Ring 18x14 ČSN 02 9280.2 189 591
1
32
Ring 14x18 AL ČSN 02 9310.3 106 539
2
33
Gufero sealing 17x30x7 ČSN 02 9401.0 9943223
1
34
Gufero sealing 25x47x7 ČSN 02 9401.0 124 505
2
35
Feather 6x6x20 ČSN 022562 196 536
1
