BDR-595 E EuroAdela
30
Pos. Name Size Drawing-Standard Order. No. Pcs
1 Frame assembly 22 9 1536 050 196 001 1
2 Apron frame-front 22 9 1856 008 196 018 1
3 Apron frame-rear 22 9 1856 009 196 019 1
4
5 Upper housing 22 9 8545 029 196 020 1
6 Mud-guard flap holder 32 0 1530 129 196 012 1
7
8 Mud-guard flap 32 0 8530 036 189 115 1
9
10 Mud-guard flap support 32 0 9230 010 182 010 1
11
12 Pillar 632 0 1520 049 196 525 1
13 Rear pillar 632 0 1520 050 196 526 1
14 Apron 632 0 1840 073 196 514 1
15 Left mud guard 632 0 8545 045 196 506 1
16 Right mud guard 632 0 8545 046 196 505 1
17 Lower housing 632 0 8545 047 196 513 1
18
19 Bolt M6x16
ČSN 02 1103.25
189 552 10
20 Bolt M6x20
ČSN 02 1103.25
189 551 9
21 Bolt M8x16
ČSN 02 1103.25
106 547 2
22 Bolt M8x30
ČSN 02 1174.25
196 537 2
23 Nut M6
ČSN 02 1492.25
168 516 15
24 Nut M8
ČSN 02 1492.25
104 622 3
25 Washer 6,4
ČSN 02 1702.15
189 571 15
26 Washer 8,4
ČSN 02 1702.15
131 517 1
27 Washer 6,6
ČSN 02 1727.15
169 508 16
28
29
30 Washer 9
ČSN 02 1729.05
150 536 2
31 Washer 8,2
ČSN 02 1740.05
104 574 2
32
33 Nut cap 034-03-M6
SUNAP Neratovice
169 505 6
34 Nut cap 034-03-M8 (13)
SUNAP Neratovice
169 504 2
35
36
Machine casing
