Vari BDR-595 E EuroAdela - 5 Machine: Its Use, Technical Specification and Description; Use of the Machine; Technical Specification

BDR-595 E EuroAdela
9
5 Machine: Its use, technical specification and description
5.1 Use of the machine
Drum mower Model BDR-595 EuroAdela has been designed and manufactured to the
latest knowledge in the field of small gardening and farming machinery, its design meeting
the most recent European safety standards binding for this machine category. It also excels in
easy maneouvrability and problem-free maintenance.
The mower is meant for cutting thin-walled stalky grass stands of medium height up to
max. 80 cm on well-kept (i.e. annually mown) surfaces. The mown surfaces must be without
any solid articles in the stand and greater terrain roughness. The mower is not meant for park
treatment of grass stands neither for cutting stands with even a minimum representation of
woody plants arisen from self-seeding.
,Engagement width has to be at all times accommodated to the density of
mown stands
5.2 Technical specification
BDR-595 E EuroAdela Unit Value
Length (incl. protective screen) mm 1745
Width (incl. protective screen) mm 978
Height (incl. protective screen) mm 1120
Weight kg 61
Max. engagement width cm 56
Mowing disk speed (at max. engine rotations) min
-1
2068
Circumferential speed of knives (at max. engine
rotations)
m.s
-1
60.3
Travel speed (at max. engine rotations) km.hr
-1
2.7
Area performance (according to stand type) m
2
/hr 800-1400
Gear box oil filling litres 0.15
Oil grade API GL - 4, GL – 5
SAE 90, 80W - 90
Engine type Unit Value
HONDA GCV 160
-- --
Cylinder volume cm
3
160
Drilling x Lift mm 64x50
Max. output at RPM kW/rpm 4.1/3600 (5.5HP)
Max. torque at RPM N.m/rpm 11.4/2500
Maximum engine speed adjustment rpm 3200 (+/-100)
Tank volume litres 1.1
Petrol (leadless) oct.no. 91-95
Oil filling litres 0.55
Oil SAE 15W-40
Spark plug -- NKG BPR6ES
-- BRISK LR15YC
