DS-521D, DS-521DB
1) Middle cover
2) Left side cover
3) Right side cover
Pict. 2: Assembly of lower cover
1) Disc drive clutch level
2) Wheel drive clutch lever
3) Handlebars fastening bolt
4) Accelerator lever (gas lever)
5) Side screen fastening bolt
6) Side screen
7) Cutting disc
8) Blades (4 pieces)
9) Cutting disc cover EN 12 733
10) Disc cover
11) Frame - tube
12) Handle
13) Engine
14) Fuel tank lid
15) Wheel
16) Gearbox cover
Pict.3: Description of the main parts
Position STOP:
Engine is not running (position ‘1’)
➢ Used for turning off the running engine.
➢ Putting the machine out of service.
➢ Refuelling
➢ Machine transport
Position MIN:
Engine is running at idle. (position „2“ turtle)
➢ Short work break
Position MAX:
Engine is running at maximum rpm. (position „3“
hare)
➢ Working position
Position CHOKE:
Engine is running. (position „4“)
➢ Cold engine start
Pict. 4: Positions of accelerator lever
Pict. 5: Cutting width
Pict. 6: Lubricating point
Pict. 7: Lubricating point
Pict. 8: Lubricating point
Pict. 9: Lubricating point
Pict. 10: Lubricating point
Pict. 11: Adjustment of the wheel drive tightening pulleys
Pict. 12: Disc drive clutch lever – brake
Pict. 13: V-belt track
Pict. 14: Safety pictogram - Machine wheel drive
Pict. 15: Safety pictogram - Starting up the disc
Pict. 16: Safety pictogram – Combined sticker Location on the machine
Pict. 17: Safety pictogram - Arrow direction of turning
Pict. 18: Safety pictogram – Dangerous area
1) Lever of the disc drive clutch
2) Safety lock button
3) Stirrup with wires
Pict. 19: Lever of the disc drive clutch
27
