LEG ASSEMBLY INSTALLATION
(1) Pipe Handle 1/2” x 6”
1
(4) Bushing Reducer 1/2”
Axle 5/8” OD X 2”
3
(2) Leg Welded Assembly
2
(1) Handle grip
4
(2) Tube Cap 1.5”
5
(2) Washer 1/4” Split Lock
6
(4) RIVNUT 1/4-20 GRP.027-
1.65 RIB
7
8
(2) Bolt 1/4-20 X 1 GR 5
Zinc Hex
(4) Washer 3/8” Split Lock
9
10
(4) Bolt 3/8-16X2-1/2 Zinc
Hex
11
(4) Bolt 1/2-13UNC X 3”
12
(4) Wheel Pneumatic 10”
5/8” Bore
