3. Acquiring PANO Images
34 Green X (PHT-75CHS) User Manual
<Sinus Mode (LAT/PA)>
Patient Positioning
1. Remove the Normal Chinrest and insert the Special Chinrest into the
equipment.
2. Insert the Special Bite A into the Special Chinrest
Clean the Chinrest and the Bite with ethanol and wipe with a
dry towel before the next patient.
3. Use the Temple Supports OPEN/CLOSE wheel on the handle frame to widen
the Temple Supports. (Turn the wheel counterclockwise to open Temple
Supports.)
4. Guide the patient to the equipment.
Special Bite A
Special Chinrest
To Next Page
