VC 7210 - Page 19

VC72XX_HW.pdf – Hardware Documentation VC72XX Smart Cameras
 1996-2016 Vision Components GmbH Ettlingen, Germany
19
Suggested Trigger Input Circuit PNP (PWR < 1.2)
Suggested Trigger Input Circuit PNP (PWR >= 1.2)
47 Ω
47 Ω
Trig In, Pin 6
GND, Pin 3
TTL Input
3.3V Out, Pin 2
Trig In, Pin 6
GND, Pin 3
10k
TTL Input
2k2
Camera Circuit
Trigger Input Circuit
5V Out, Pin 2
Camera Circuit
Trigger Input Circuit
