VC 7210 - Page 20

VC72XX_HW.pdf – Hardware Documentation VC72XX Smart Cameras
 1996-2016 Vision Components GmbH Ettlingen, Germany
20
Suggested Trigger Input Circuit NPN (PWR < 1.2)
Suggested Trigger Input Circuit NPN (PWR >= 1.2)
R
R
GND, Pin 3
Trig In, Pin 6
47 Ω
Trig In, Pin 6
GND, Pin 3
10k
TTL Input
R
R
2k2
Camera Circuit
Trigger Input Circuit
3.3V Out, Pin 2
Camera Circuit
Trigger Input Circuit
5V Out, Pin 2
