Vector TCI-C Series User Manual

TCI-C-Universal Controller
Doc: 70-00-0123, Date: 20091020 © Vector Controls GmbH Page 2
Ordering
Model Stock code Option
Control
lp
Temp In
PT1000
UI DO
Relays
AO Power Housing
TCI-C11-0 40-11 0060
1 0 2 2 1
24VAC
Cabinet,
DIN rail
mounted
TCI-C11-0-D 40-11 0061 Deluxe
TCI-C11-2 40-11 0062
230VAC
TCI-C11-2-D 40-11 0063 Deluxe
TCI-C22-0 40-11 0064
2 1 3 2 2
24VAC
TCI-C22-0-D 40-11 0065 Deluxe
TCI-C22-2 40-11 0066
230VAC
TCI-C22-2-D 40-11 0067 Deluxe
Technical specifications
Power Supply
Product type TCI-Cxx-0 TCI-Cxx-1 TCI-Cxx-2
Operating Voltage ±10%, 50/60 Hz 24 VAC 110VAC 230VAC
Power Consumption Max. 3 VA Max. 5 VA Max. 5 VA
Electrical Connection Terminal Connectors,
wire 0.34…2.5 mm
2
(AWG 24…12)
Clock backup Min. 48 hours
Signal inputs
Universal Input
Input Signal
Resolution
Accuracy
Setting for Voltage or Current
0...10 V or 0...20 mA
9.76 mV or 0.019 mA (10 bit)
± 2 %
Universal Input Setting for temperature input or open contact
Range NTC (Sxx-Tn10 sensor): -40…140 °C (-40…284 °F)
Accuracy -40…0 °C (-40…32 °F): 0.5 K
0…50 °C (32…122 °F): 0.2 K
50…100 °C (122…212 °F): 0.5 K
> 100 °C (> 212 °F): 1 K
PT1000 input
Range
Accuracy
PT according EN 60751
-50…200°C (-58…392)
± 0.5%
Signal outputs
Analog Outputs
Output Signal
Resolution
Accuracy
Maximum Load
DC 0...10 V or 0...20 mA (500 Ω max.)
9.76 mV resp. 0.019 mA (10 bit)
± 1 %
20 mA, 500 Ω max.
Relays Outputs
AC Voltage
DC Voltage
Insulation resistance
0…250 VAC, 8 (5) A max. each output
0…30 VDC, 8 (5) A max. each output
3750 VAC acc. to EN 60 730-1
Environment
Operation
Climatic Conditions
Temperature
Humidity
To IEC 721-3-3
class 3 K5
0…50 °C (32…122 °F)
<95 % r.H. non-condensing
Transport & Storage
Climatic Conditions
Temperature
Humidity
Mechanical Conditions
To IEC 721-3-2 and IEC 721-3-1
class 3 K3 and class 1 K3
-25…70 °C (-13…158 °F)
<95 % r.H. non-condensing
class 2M2
Standards
conform according to
EMC Standard 89/336/EEC
EMEI Standard 73/23/EEC
EN 61 000-6-1/ EN 61 000-6-3
Product standards
Automatic electrical controls for
household and similar use
Special requirement on temperature
dependent controls
EN 60 730 –1
EN 60 730 – 2 – 9
Degree of Protection IP30 to EN 60 529
Safety Class II (IEC 60536)
Cover, back part Fire proof ABS plastic (UL94 class V-0)
General
Dimensions (H x W x D) 60 x 93 x 93(110*) mm (2.4” x 3.7” x 3.7(4.3*)”)
*)
Din rail mounting
Weight (including package) 240 g (8.5 oz)
