TCI-C-Universal Controller
Doc: 70-00-0123, Date: 20091020 © Vector Controls GmbH Page 8
Setting of parameters
The TCI is an intelligent controller and can be adapted to fit perfectly into your application. The control operation is
defined by parameters. The parameters are set during operation by using the standard operation terminal.
The parameters are password protected. There are two levels of parameters: User operation parameters for access control
settings and Expert parameters for control functions and unit setup. The passwords for user levels and expert levels are
different. Only control experts should be given the control parameter password.
The parameters can be changed as follows:
1. Press UP and DOWN button simultaneously for three seconds. The display will indicate the firmware version in the
upper large digits and the revision in the lower small digits. Press the RIGHT or POWER key to start login
2. CODE is shown in small display.
3. The code for accessing the user parameters is 009
4. Select this using UP or DOWN buttons.
5. Press the RIGHT or POWER button after selecting the correct code.
6. Once logged in, the parameter is displayed immediately.
7. Select the parameters with the UP/DOWN buttons. Change a parameter by pressing the RIGHT button. Arrows 8 to 10
show up and indicate that the parameter may be modified now. Use UP or DOWN buttons to adjust the value.
8. After you are done, press RIGHT or POWER in order to save the new value of the parameter and return to the
selection level. Pressing LEFT key will discard the value and return without saving.
9. Press the LEFT button to leave the menu. The unit will return to normal operation if no button is pressed for more
than 5 minutes.
User Parameters (Password 009)
Parameter Description Range Default
UP 00 Enable access to operation modes ON, OFF ON
UP 01 Enable access to set points ON, OFF ON
UP 02 Enable manual control in cascade or fan control mode ON, OFF ON
UP 03 Enable change of heating / cooling mode for 2 pipe systems ON, OFF ON
UP 04 Enable access to time programs: ON, OFF ON
UP 05 State after power failure:
0 = off, 1 = on, 2 = state before power failure
0, 1, 2 2
UP 06 Enable standby functionality ON, OFF ON
UP 07 Celsius or Fahrenheit, ON for Fahrenheit, OFF for Celsius ON, OFF OFF (Celsius)
UP 08 User Display: Select display while no key is pressed ON, OFF ON
UP 09 Select contents of Large LCD display in standard mode: 0…5 1
00 = OFF
01 = Input
02 = Setpoint
03 = Analog Output
04 = Binary Output
05 = Clock
UP 10 Select ID of contents of upper digit display 0…4 1
UP 11 Select contents of lower digit display in standard mode 0…5 Standard = 2
Deluxe = 5
UP 12 Select ID of contents of lower digit display 0…4 1
UP 13 Select analog output for display in vertical bar
00 = OFF
01 = AO1
02 = AO2
03 = FO1
04 = Output lp1
05 = Output lp2
0…5 3
UP 14 ON = Display heating & cooling state of controller in standard mode
OFF = Do not indicate heating and cooling state in standard mode
ON, OFF OFF
UP 15 ON = Alarms blink after being active and need to be confirmed
OFF = Alarms are only shown when they are active
ON, OFF ON
UP 16
Deluxe only
Clock display type:
OFF = Show 24hour clock
ON = Show 12hour clock (AM, PM)
ON, OFF OFF (24h)
UP 17
Deluxe only
Reset timer for override mode: Only available for deluxe version
0 = Reset of override mode is not active. Time schedules can be overridden
manually.
1…255 = delay in minutes to switch off device if ON/Economy mode is activated
while the unit is scheduled to be in OFF mode
0…255 60 (Min)
