Manual VN5610/VN5610A Version 2.0 3
Contents
1 Introduction 5
1.1 About this User Manual 6
1.2 Important Notes 7
1.2.1 Safety Instructions and Hazard Warnings 7
1.2.1.1 Proper Use and Intended Purpose 7
1.2.1.2 Hazards 8
1.2.1.3 Disclaimer 8
1.2.2 Certification 9
1.2.3 Warranty 9
1.2.4 Registered Trademarks 9
2 Device Description 10
2.1 Scope of Delivery 11
2.2 Introduction 11
2.3 Accessories 12
2.4 Examples of Usage 13
2.4.1 Standalone Media Converter 13
2.4.2 Transparent Ethernet Monitoring 13
2.4.3 Remaining Bus Simulation 17
2.4.4 Diagnostics over IP 18
2.4.5 Avionics Full Duplex Switched Ethernet 19
2.5 VN5610 20
2.5.1 Connectors Ethernet Side 20
2.5.2 Connectors USB Side 21
2.5.3 LEDs 23
2.5.4 Technical Data 24
2.6 VN5610A 26
2.6.1 Connectors Ethernet Side 26
2.6.2 Connectors USB Side 27
2.6.3 LEDs 29
2.6.4 Technical Data 30
3 Getting Started 32
3.1 Driver Installation 33
3.2 Device Configuration 35
3.3 Loop Tests 37
3.4 Ethernet 37
