Welcome to Vector Lab Products
Vector Lab Products equipment enjoys a well-deserved reputation for excellent performance, long-term reliability
and outstanding after-the-sale support. To ensure that this product delivers that same degree of service, we ask
that you take a moment to review this manual before beginning the installation. Should you have any questions or
require technical help at any point, please call our technical service group at 1-855-686-5592.
Before you begin
Do not tilt unit further than 30° off vertical during uncrating or installation. After uncrating and removing all packing
material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately
and contact Vector Lab Products so that we can help in the ling of a claim, if necessary.
Check your paperwork to determine which conguration you have. Vector Lab Products conguration numbers are
designed to provide information about the type of refrigerator you are receiving. Following is an explanation of the
different item numbers.
Model Number
Width
(inches)
Depth
(inches)
Height
(inches)
Ref. Volume
(cu.ft.)
Set Point
Temp.
Elec.
V/Ph/Hz
Cooling
Capacity
Absorbed
Power
VREF12-LB-RGD
VREF12-LB-SGD
23 5⁄8 23 5⁄8 71 23⁄32 12 4 C 120/1/60 699 BTU 260 W
VREF12-LB-RSD 23 5⁄8 23 5⁄8 71 23⁄32 12 4 C 120/1/60 699 BTU 260 W
VREF25-LB-RSD 28 11⁄32 31 1⁄2 79 3⁄16 25 4 C 120/1/60 1467 BTU 290 W
REF25-LB-RGD
REF25-LB-LGD
28 11⁄32 31 1⁄2 79 3⁄16 25 4 C 120/1/60 1467 BTU 290 W
VFZR25-LB-RSD
VFZR25-LB-LSD
28 11⁄32 31 1⁄2 79 3⁄16 25 –20 C 120/1/60 1774 BTU 500 W
VREFCR30-RGD 32 9⁄32 37 31⁄64 81 5⁄32 30 4 C 120/1/60 1774 BTU 500 W
VREF30-LB-RSD 32 9⁄32 37 31⁄64 81 5⁄32 30 4 C 120/1/60 1774 BTU 500 W
VREF30-LB-RSD
VREF30-LB-LSD
32 9⁄32 37 31⁄64 81 5⁄32 30 4 C 120/1/60 1774 BTU 500 W
VREF49-LB-SGD 56 11⁄16 31 1⁄2 79 3⁄16 49 4 C 120/1/60 1774 BTU 470 W
VFZR49-LB-OSD 56 11⁄16 31 1⁄2 79 3⁄16 49 –20 C 120/1/60 2501 BTU 750 W
VREF49-LB-OSD 56 11⁄16 31 1⁄2 79 3⁄16 49 4 C 120/1/60 1842 BTU 470 W
VREF49-LB-OGD 56 11⁄16 31 1⁄2 79 3⁄16 49 4 C 120/1/60 1842 BTU 470 W
VREF72-LB-RSD 85 3⁄64 31 1⁄2 79 3⁄16 72 4 C 120/1/60 2*1467 BTU 600 W
VREF72-LB-RGD 85 3⁄64 31 1⁄2 79 3⁄16 72 4 C 120/1/60 2*1467 BTU 600 W
