Vector Lab Products Refrigerators and Freezers 17
Door Gasket Replacement
Fig. 5
1. Remove existing gasket from mounting track (Fig. 5).
2. Verify mounting track is free of any remaining gasket material.
3. Align new gasket with mounting track and press rmly in place.
4. Open and close door, checking for proper gasket seal without
pinching against refrigerator.
Modular Refrigeration System
Vector Lab Products’ Modular Refrigeration System allows technicians to
remove the entire unit from the refrigerator top.
1. Remove rear support column using 5/16" nut driver.
2. Remove incoming power supply assembly.
3. Remove bolts securing unit cooler to refrigerator top.
4. Gently lift off cooler.
