3-2
A. Planetary Gearbox/Brushless DC Motor/Encoder
• Planetary Gearbox
This single stage gearbox is mounted to the rear
wheel and is permanently sealed and lubricated
so that it requires no maintenance. The gearbox
is vented by means of a small vent cap
located on the top side of the motor. For vent cap
maintenance see page 5-4.
• Brushless DC Motor
The brushless DC motor is mounted in the left side
of the swingarm. The motor shaft is connected to
the gearbox in the rear wheel.
• Encoder
The encoder is located behind a sealed cover
that is under the swingarm chrome cover, on
the left side of the swingarm. Do not remove
the sealed cover. This cover seals out dirt and
moisture, protecting the adjustment to the encoder.
B. Motor Controller
The motor controller is the “brain” of
the scooter, providing the interface between the
battery pack and the motor. It is located just
behind the battery pack.
Only your authorized Vectrix dealer is qualied to
troubleshoot the motor controller.
WARNING: Removal of the cover and/or
modication of the motor controller by any means
will void the warranty and is extremely hazardous.
C. Battery Pack
CAUTION:
Opening battery pack is dangerous and can cause
injury or death from electrocution. DO NOT OPEN!
Opening the battery pack will void your warranty.
Only your authorized Vectrix dealer is qualied to
troubleshoot a battery related issue.
Proper care of your battery pack is essential for
maximum performance. Maximum performance is
reached after you have performed ve (5) initial
charge/deep discharge cycles. Each initial deep
discharge/charge will improve your range.
The battery pack must be kept within a preset
operating temperature window. The battery system
includes fans that draw outside air through the
battery pack. These cooling fans are turned on
in response to temperature, or when you are
charging the battery.
