3-11
D. Bluetooth Indicator
Not Used. In place for future enhancements.
E. RF Range Indicator
Not Used. In place for future enhancements.
F. Estimated Range Display
This displays the estimated range available (km
or miles) based on your recent driving prole. Hard
accelerations and high speeds will decrease
this value; soft accelerations and slower speeds
will increase this value. During the charging process
this displays the battery voltage.
G. Trip Odometer Display
You can display individual trip mileage in either
kilometers or miles. It can be reset by pressing
the “S” on the instrument cluster controls.
See Instrument Cluster Controls on page 3-15.
H. Odometer/Trip A-B Display
This displays the mileage of the currently selected
trip or odometer. Use the instrument cluster control
button marked “E/M” to switch the display values
between km or miles. During the charging
process this will display the highest battery module
temperature in C°.
I. Odometer/Trip A-B Display Setting
This indicates the mileage reading currently
displayed. Use the instrument cluster control button
marked “S” to switch between Trip A, Trip B or the
odometer.
J. GO Indicator
This indicator will illuminate when the system is
enabled and ready to accelerate.
