1-7
DIMENSIONS
Weight Li = 193 kg (425 lbs)
Li+ = 209 kg (460 lbs)
Wheelbase 1524 mm (60 in)
Seat Height 775 mm (30.5 in)
Storage Capacity Trunk: 1.41 cu ft (1 full-
faced helmet)
Glove Compartment: .21
cu ft
Optional Cargo Box: up to
1.66 cu ft
Carrying Capacity 2 passengers
* The Gross Vehicle Weight Rating (GVWR) is the
combined weight of the scooter, passengers and cargo.
** The Gross Axle Weight Rating (GAWR) is the maximum
allowable weight that can be placed on an individual axle.
WEIGHT
Gross Vehicle Weight
Rating (GVWR)*
425 kg (938 lbs)
Gross Axle Weight Rating
(GAWR) Front**
153 kg (338 lbs)
Gross Axle Weight Rating
(GAWR) Rear**
272 kg (600 lbs)
STORAGE (Maximum Load)
Trunk 12 kg (26 lbs)
Glove Compartment 2 kg (4 lbs)
Optional Cargo Box 9 kg (20 lbs)
WARRANTY
Warranty 24 months
EMISSIONS
Emissions Pollutants: Zero
CO2: Zero
Exhaust Noise: Zero
