4 Vac System Testing - TLS-350/350R Consoles Vac Sensor Setup
4-2
Press ENTER to accept your label:
Press STEP:
Press CHANGE until you see the message:
Press ENTER to accept the category. Press STEP, then BACKUP to return to the configuration display for Smart
Sensor module 1:
This completes the ATM Pressure Sensor configuration.
Vac Sensor Setup
IDENTIFYING VAC SENSOR ZONES
Before configuring the Vac Sensors, enter the Monitored Zone, Smart Sensor module number, and channel
number for each Vac Sensor attached to the console in the worksheet in Table 4-1 below. NOTE: The Vac Sensor
Zone Worksheet and the Secondary Containment Volumes By Manufacturer index are both included in the
installation kit (P/N 577013-849). Use the Containment Volume index to calculate a zone’s interstice volume in
gallons. For example, if Tank 1’s double wall product piping uses 100 feet of Ameron Dualoy 3000/L piping, you
would multiply 0.2186 (from the Secondary Containment Volume index) x 100 feet = 21.86 gallons. For the Tank 1
product piping zone you would enter 21.9 (round to nearest tenth of a gallon) as the calculated zone volume. If the
Tank 1 sump is a Containment Solutions 42” Double wall tank sump, you would you would multiply 0.8216 (from
the Secondary Containment Volume index) x 3.5 feet = 2.88 gallons as the calculated zone volume.
Table 4-1.- Vac Sensor Zone Worksheet
Vac Sensor Monitored Zone
SS Module
Number
SS Module
Channel Number
Calculated
Zone Volume
(Gallons)
11
12
13
14
15
16
17
s 8: (ATMP Sensor Label)
PRESS <STEP> TO CONTINUE
s 8: SELECT SS CATEGORY
UKNOWN
s 8: SELECT SS CATEGORY
ATM P SENSOR
SS CONFIG - MODULE 1
SLOT x - X X X X X X X X
