Veeder-Root TLS-450 PLUS - Fixed Comm Module Port Assignments

Page 7
USB ports: 1 (upper), 2 (lower)
Future expansion port
Ethernet port 1 (upper )
Ethernet port 2 (middle)
Switch port (lower)
Comm Bay Slots
Front of
Console
1 2345
Port Assignments For Fixed Comm Modules In Comm Bay Slots 4 & 5
