5Setupwiththedisplayandadjustmentmodule
MINITRAC 31 • Foundation Fieldbus
62076-EN-190704
In this menu item you can enter the inside diameter of the tube or the
radiatedlength(L).
Thissettinginuencestheaccuracyofthesensor.
First of all, select the unit of the inside diameter.
Enterinthemenuwindow"Inside diameter" the inside diamter of the
tube,forexamplein"cm".
Ifthetubeisnotradiatedwith90°,thenyouhavetoentertheradiated
length(L)insteadofthetubeinsidediameter.
Enteralsoheretheradiatedlengthwithoutthewallthicknessofthe
tube.
L
Fig. 19: With inclined mounting, the radiated length of the tube is applicable
Inner diameter
