14 Supplement
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
14.3 Communication
Register Num-
ber
Register Name Data type CongurableValues Unit Default
Value
200 Address uint8
r/w
1 … 255 – 246
201 Baud Rate enum16
r/w
1200, 2400, 4800, 9600,
19200, 38400, 57600
– 9600
202 Parity enum8
r/w
0 = None, 1 = Odd, 2 =
Even
– 0
203 Stopbits enum8
r/w
1 = None, 2 = Two – 1
206 Delay Time uint16
r/w
10 … 250 ms 50
14.4 Setup
Register Num-
ber
Register Name Data type CongurableValues Unit Default
Value
3000 Byte Oder (Floating point
format)
enum8
r/w
0=ABCD, 1=CDAB,
2=DCBA, 3=BADC
– 0
3200 Distance unit enum16
r/w
44=ft, 45=m, 47=in,
49=mm
- m
3201 Temperature unit enum16
r/w
32=°C, 33=°F, 35=K - °C
3401 Min.-Adjustment oat32
r/w
0 ... Measurement range - 0
3403 Max.-Adjustment oat32
r/w
0 ... Measurement range - Measure-
ment range
3600 Medium type enum16
r/w
0=Liquids, 1=Solids - Liquids
3601 Application liquid enum16
r/w
0 =Storage tank, 1=
Storage tank (product ag-
itation), 2=Cargo tank,
3=Reactor tank, 4=Dos-
ing tank, 5=Stilling pipe,
6=Bypass, 7=Outside of
plastic tank, 8=Outside
of mobile plastic tank,
9=Level of open water,
10=Openume,11=Water
weir, 12=Demonstration,
13=Pump station, 14=Col-
lection tank
- Storage
tank
