14 Supplement
VEGAPULS C 23 • Modbus and Levelmaster protocol
58349-EN-200806
Register Num-
ber
Register Name Data type CongurableValues Unit Default
Value
3602 Application solid enum16
r/w
0=Silo, 1= Bunker Big,
2=Bunkerfastlling,
3=Prolregistrationheap,
4=Breaker mill, 5=Demon-
stration
- Silo
14.5 Measured values
Register Number Register Name Data type
Access
Note
100 Status enum8
ro
Bit 0: Invalid Measurement Value PV, Bit 1: Invalid Meas-
urement Value SV, Bit 2: Invalid Measurement Value TV, Bit
3: Invalid Measurement Value QV
104 PV Unit enum16
ro
32=Degree Celsius, 33=Degree Fahrenheit, 40=US Gal-
lons, 41=Liters, 42=Imperial Gallons, 43=Cubic Meters,
44=Feet, 45=Meters, 46=Barrels, 47=Inches, 48=Centim-
eters, 49=Millimeters, 111=Cubic Yards, 112=Cubic Feet,
113=Cubic Inches
106 PV oat32
ro
Primary Variable in Byte Order CDAB
108 SV Unit enum16
ro
Unit Code
110 SV oat32
ro
Secondary Variable in Byte Order CDAB
112 TV Unit enum16
ro
Unit Code
114 TV oat32
ro
Third Variable in Byte Order CDAB
116 QV Unit enum16
ro
Unit Code
118 QV oat32
ro
Quarternary Variable in Byte Order CDAB
1300 Status enum8
ro
See Register 100
1302 PV oat32
ro
Primary Variable in Byte Order of Register 3000
1304 SV oat32
ro
Secondary Variable in Byte Order of Register 3000
1306 TV oat32
ro
Third Variable in Byte Order of Register 3000
1308 QV oat32
ro
Quarternary Variable in Byte Order of Register 3000
