Veit SG67 - Dimensions and Weight; Power Supply Requirements; Water Supply Specifications

Tab. 1: Dimensions and weight
Width 350 mm 13.5 inches
Depth 480 mm 19.0 inches
Height 850 mm 33.5 inches
Weight 27.5 kg 61 lbs
Tab. 2: Article number
VEIT SG67
2.2 kW
VEIT SG67
4.4 kW
VEIT SG67-C
4.4 kW
VEIT SG67
6.6 kW
Article number 150042 150000 150044 149801
Tab. 3: Power supply
VEIT SG67
2.2 kW
VEIT SG67
4.4 kW
VEIT SG67-C
4.4 kW
VEIT SG67
6.6 kW
Supply voltage 230 V 400 V 400 V 400 V
Power 2.2 kW 4.4 kW 4.4 kW 6.6 kW
Current consumption 10.5 A 10.5 A 10.5 A 10.5 A
Protection on the line side 16 A 16 A 16 A 16 A
Frequency 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
Tab. 4: Water supply
Connection Article number 152283, optionally
Intended use
Technical data
30.09.2022
Steam generator VEIT SG67
10
