LAB2: THREE IN ONE LAB UNIT
This unique unit includes a digital oscilloscope (40MS/s), a
digital function generator (1Mhz) and a simple but easy-to-
use power supply (up to 12VDC). The 3 units are electrically
separated for ease of measurement.
T
APS230: ADVANCED PERSONAL
SCOPE 240MS/s
Feature-packed 2-channel
2x30MHz oscilloscope.
Full auto-setup, numerous
readouts, several display
modes and serial interface.
Comes complete with power
adaptor, battery pack and
probes.
.
HPG1: 1MHz Pocket
Function Generator
HPS140: HANDHELD
POCKET SCOPE
40MS/s
Do not let its size fool you! This
Oscilloscope packs a lot of power in
a tiny box. Now you can really take a
powerful oscilloscope everywhere.
Powerful, compact and USB
connectivity, this sums up the
features of this oscilloscope. The
large keyboard and bright LCD
makes this unit a breeze to use,
combine this with great specifi ca-
tions and you wonder how you
ever managed without it!
PCGU1000 PCSGU250 PCSU1000
PCGU1000: 2MHz USB PC FUNCTION GENERATOR
The PCGU1000 is a digital function generator which can be connected with a PC via USB.
Standard signal waves like e.g. sine, triangle and rectangle are available; other sine waves
can be easily created.
Two channel oscilloscope, spectrum analyser, recorder, function generator and bode plotter.
With the generator, you can create your own waveforms using the integrated signal wave editor
