PPS10 Pocket Scope
TM
Survey of the connections and
controls
1. BNC input connector (max. input 100Vp
AC+DC)
2. Adapter connection (observe the polarity!)
3. RS232 connection
4. X10 probe testing signal
5. Reset button
6. Battery compartment
USE
Use
9V DC
PC
interface
2
1
3
4
5
6
6
Fig 5.0
Fig 6.0
+
-
+
+
-
-
-
-
+
+
