PPS10 Pocket Scope
TM
Readout Setup
Press the MENU button to call the setup
menu. Use the joystick to select ‘Meter’ under
‘Keymode’ and press the joystick (fig. 64).
A table with all possible readout setups for
‘METER-1’ appears on the display (fig.
65A). Select the desired readout with the
joystick. Lock your choice with a short press
on the joystick.
Depending on the display layout you can
choose up to 4 different readouts (fig. 65A to
65D). The choice for ‘METER-2’, ‘METER-
3’ and ‘METER-4’ readouts occurs analogi-
cally. Quit the setup menu any time by press-
ing the MENU button.
Fig 62 Fig 63
Menu
Fig 64 Fig 65A
Fig 65B Fig 65C Fig 65D
Readout setup
Joystick
Manette
