KEY PART
QTY PER SERIE
NO.NO.
D
ESCRIPTION C600E
C600M V40E
ED600E
1 13296 A
DAPTER/DAMPER 111
2 16153 S
MOKED GLASS 11-
16150 G
LASS HOLDER BLACK (THE PAIR)11-
3 16151 GLASS HOLDER WHITE (THE PAIR)11-
16152 GLASS HOLDER GREY (THE PAIR)11-
4 01988 B
LOWER WHEEL 222
5 01757 I
NLET RING 222
6 14131 M
ICROMESH FILTERS (THE PAIR)--1
06941 STAINLESS STEEL FILTERS (THE PAIR)11-
*
07020 INSTALLATION & USER MANUAL 111
H
ARDWARE BAG: (2) WIRE CONNECTORS,
*
04281 (
1) WIRE CLAMP, (6) NO. 6 X 1/2” SCREWS,
111
(5) NO.8X 1/2” DOUBLE THREAD SCREWS
12. SERVICE PARTS
- 12 -
KEY PART
QTY PER SERIE
NO. NO.
D
ESCRIPTION
C180
HDN17
V10, V30
1 13296 A
DAPTER/DAMPER 11
2 16153 S
MOKED GLASS 1-
16150 G
LASS HOLDER BLACK (THE PAIR)1-
3 16151 G
LASS HOLDER WHITE (THE PAIR)1-
16152 G
LASS HOLDER GREY (THE PAIR)1-
4 01988 BLOWER WHEEL 11
5 01757 INLET RING 11
6 14131 M
ICROMESH FILTERS (THE PAIR)11
*
07020 INSTALLATION & USER MANUAL 11
*
04281
HARDWARE BAG: (2) WIRE CONNECTORS,
11
(
1) WIRE CLAMP, (6) NO.6X 1/2” SCREWS,
(5)
NO.8X 1/2” DOUBLE THREAD SCREWS
SINGLE BLOWER RANGE HOODS
C180, HDN17, V10 AND V30 SERIES
* Item not shown
C270, C370, ED370, ROB15, ROB35, ROV15 AND
ROV35 SERIES
* Item not shown
DOUBLE BLOWER RANGE HOODS
C600E, ED600E, C600M AND V40E SERIES
* Item not shown
KEY
NO.
PART
NO.
DESCRIPTION
QTY PER SERIE
C270
C370
ED370
ROB15
ROB35
ROV15
ROV35
1
13296 ADAPTER/DAMPER
1 1 1 -
2
16153 SMOKED GLASS
1 1 - -
3
16150 GLASS HOLDER BLACK (THE PAIR)
1 1 - -
16151 GLASS HOLDER WHITE (THE PAIR)
1 1 - -
16152 GLASS HOLDER GREY (THE PAIR)
1 1 - -
4
01988 BLOWER WHEEL
1 1 1 1
5
01757 INLET RING
1 1 1 1
6
14131 MICROMESH FILTERS (THE PAIR)
1 - 1 1
06941 STAINLESS STEEL FILTERS (THE PAIR)
- 1 - -
*
07020 INSTALLATION & USER MANUAL
1 1 1 1
*
04281
HARDWARE BAG:
(2) WIRE CONNECTORS,
(1)
WIRE CLAMP, (6) NO.6X 1/2” SCREWS,
(5)
NO.8X 1/2” DOUBLE THREAD SCREWS
1 1 1 1
