Step 3
Insert the other side of the pole to the square hole of
the plastic stand.
NOTE:
Align the pole and stand marking.
Step 4
Place the nut in the hexagon hole of the stand, then
insert the screw in other side and then tighten it by
the screw driver.
Step 5
Mount the wireless 7-IN-1 sensor with the wind meter end pointing to the North to correctly
orient direction of the wind vane.
A. Mounting on pole (Pole Diameter 1"~1.3")
(25~33mm)
B. Mounting on the railing
NOTE:
1. Install the wireless 7-IN-1 sensor at least 1.5m off the ground for better and more accurate
wind measurements.
2. Choose an open area within 150 meters from the LCD console.
3. Install the wireless 7-IN-1 sensor as level as possible to achieve accurate rain and wind
measurements.
