© 2023 Veolia. All Rights Reserved. Sievers TOC-R3 Analyzer Installation Guide DQS 95000-01 EN Rev. A
*Sievers is a trademark of Veolia and may be registered in one or more countries.
Operating Specifications
Analysis Modes TC, NPOC, TN
b
, TOC
diff
, POC/VOC, TIC
Ranges NPOC/TOC
diff
: 0-10; 0-200; 0-2,000; 0-10,000 with Dilution to 50,000 ppm;
TOC Wide Range: 0-200 and 200-20,000;
TN
b
: 0-150 and 0-1,500 ppm; POC/VOC: 0-25 ppm;
Options/Accessories Leak detection, Sample Stream 2, Particulate Sampler, Air Box, Communication
Box, Mounting Rack
Features Auto Calibration, Dilution, Check Function, Auto Rinse, Connectivity
(Remote Control), Predictive Maintenance
Precision +/-2% End of detector range†
Linearity R² ≥0.997†
LOD <1 ppm†
Analysis Time 3-5 min typically
Smallest Inner Diameter (ID) 2 mm smallest tubing diameter
Salt Tolerance 3-5% NaCl
Carrier Gas CO2 free air < 1 ppm CO2 and < 0.1 ppm hydrocarbon: 100-200 kPa
@ 30-50 L/hr flow rate (Optional: Air Box)
Sample Temperature 2-60 °C (35.6-150 °F)
Ambient Temperature 2-40 °C (35.6-104 °F)
Minimum Sample Flow Rate 100 mL/min without Particulate Sampler or 11.7-50 LPM (3.1-13.2 US gal/min)
with Particulate Sampler
Drain Gravity, No back pressure
Analyzer Specifications
Communication Protocols OPC-UA, Modbus TCP/IP
Inputs Digital Input (4)
Display 7 in. Touch panel
Power AC 110-230 V ±10 V, 50/60 Hz, 400-600 VA
Outputs
Ethernet, 4-20 mA (6), Programmable Digital Relay (4)
Installation/Overvoltage Category II
Available Configurations Single-Stream or Two-Stream (Optional)
Dimensions 900 H x 644.3 W x 354.5 D mm (35.5 H x 25.4 W x 14 D in)
Weight 55 kg (121 lb)
Safety Certifications CE, UL, CSA
Regulatory DIN EN 1484 /ISO 8245, EPA 415.3, SM 5310B, ASTM D5173, HJ 501,
DIN EN 12260
Environment
Enclosure Standard: IP-54, Option: ATEX Zone 1 & 2 T4, IECEx Zone 1 & 2 T4, C1D2
Maximum Relative Humidity Up to 85%, non-condensing
†Stated analytical performance achieved under ideal laboratory conditions.
System Specications
