VeriFone C18 User Manual

5
2 INSTALLATION
The Commander Site Controller and C18 workstation must be installed by a Verifone
Authorized Service Contractor (VASC) and must be set up in the following order:
1. Commander Site Controller
2. C18 Workstation
Configuring One or Two C18 Workstations
Installing one or two C18 workstations requires Ethernet cables to connect the C18 to the
router to create an in-store LAN. The printers, customer display poles, and cash drawers
use RS-232 cables to connect to the C18, and an additional Ethernet cable to connect the
router to a corporate WAN/Intranet.
Corporate
WAN / Intranet
Commander Site Controller Configuration
Commander Site Controller
C18
C18
with up to two C18 workstations
Router

VeriFone C18 Specifications

General

Memory	2GB RAM
Connectivity	Wi-Fi, Bluetooth, Ethernet
Card Reader	EMV, NFC
Operating System	Android
Payment Options	Credit/Debit, Contactless
Ports	Audio Jack
