SETUP
Connecting the e105 to a Mobile Device
16 E105 INSTALLATION GUIDE
Attaching the
Rubber Pad to the
e105
The e105 comes with two rubber pads of varied thicknesses. Depending on the
mobile device you are using, use one of these pads to fill the gap between the
e105 and your mobile device. To ensure a tight fit between the device and the
e105 as well as protecting your mobile device from scratches.
Figure 4 Attaching the rubber pad to the e105
Removing the e105
To remove the e105, hold the e105 firmly on both sides and then pull the device
upwards.
Figure 5 Removing the e105
B
A
1
2
3
5
8
0
6
9
4
7
*
*
*
*
NOTE
Do not remove the e105 from the mobile device during a transaction. A
transaction terminates when you remove the e105.
