VeriFone UX 301 User Manual

Public | External UX User Manual | Version 1.2 | July 24, 2017
UX User Manual 5
2. GET TO KNOW THE UX SUITE OF DEVICES
This section will allow the operator to understand the various aspects of the devices that make up
the UX suite. The suite of devices is the UX 301 (card reader), the UX 100 (pin pad) and the UX
401 (contactless reader).
2.1 UX 301 – FRONT
2.2 UX 301 – REAR
Anti-Removal
switch
Anti-Removal
switch
Card Slot
Mounting Stud
Holes
Status Lights
UX 100 Port (C)
Ethernet Port (E)
Power (D)
System Mode
Access
UX401 Antenna Port (B)
UX401 Power Port (A)

VeriFone UX 301 Specifications

General

Brand	VeriFone
Model	UX 301
Category	Payment Terminal
Language	English
