VeriFone Vx-520 Series APACS 40 User Manual

Customer Not Present Continued
1. The terminal will request the CSC (last 3
digits behind the card) the door number at
which the card is registered to, and nally the
numerical digits within the postcode in the
order they appear. If any of these details are
not available then press the green Enter key
to bypass. The terminal will then contact the
host for an Auth code.
2. The terminal will prompt if a customer copy
is required. If YES then press F1, else select
no by pressing F2.
VISA
Enter CSC: 123
F1
F2
F3
F4
Yes
Print Cust Copy? No
F1
F2
F3
F4
10 V
X
-520 Series APACS 40 User Guide

VeriFone Vx-520 Series APACS 40 Specifications

General

Processor	400 MHz ARM11
Display	128 x 64 pixel graphical LCD with backlight
Connectivity	Dial-up, Ethernet
Card Readers	Magnetic stripe, EMV chip
Printer	Integrated thermal printer, 18 lines per second
Operating System	Verix
Weight	500g
Operating Temperature	0° to 40° C (32° to 104° F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	5% to 90% RH non-condensing
