TERMINAL SETUP
VX 520 Setup
16 VX 520 INSTALLATION GUIDE
VX 520 Setup
This section describes the setup procedures for the VX 520 terminal. You will
learn about:
Selecting Terminal Location
Unpacking the Shipping Carton
Examining Terminal Features
Establishing Telephone Line Connections
Installing a Paper Roll in the Printer
Installing/Replacing MSAM Cards
Connecting Optional Devices
Connecting the Terminal Power Pack
Privacy Shield (Optional)
Using the Smart Card Reader
Using the Magnetic Card Reader
Selecting Terminal
Location
Use the following guidelines when selecting a location for your VX 520 terminal.
Ease of Use
Select a location convenient for both merchant and cardholder.
Select a flat support surface, such as a countertop or table.
Select a location near a power outlet and a telephone/modem line connection.
For safety, do not string the power cord in a walkway or place it across a
walkway on the floor.
Environmental Factors
Do not use the terminal where there is high heat, dust, humidity, moisture, or
caustic chemicals or oils.
Keep the terminal away from direct sunlight and anything that radiates heat,
such as a stove or motor.
Do not use the terminal outdoors.
CAUTION
The terminal is not waterproof or dustproof, and is intended for indoor use only.
Any damage to the unit from exposure to rain or dust may void any warranty.
