18
Fig.1 Fig.2
Fig.3
Fig.4
Stitch length dial
Overedge cutting
width dial
6
ADJUSTING STITCH LENGTH
Turn the stitch length dial until the required
length is indicated.
The higher the number, the longer the stitch.
This dial can adjust the stitch length from 1
to 5 mm.
ADJUSTING OVEREDGE CUTTING WIDTH
Overedge cutting width can be adjusted from 4 to 7 mm
by simply turning overedge cutting width dial according
to the kind of fabric.
It is set at standard width of 6 mm when delivered from
the factory.
Turn it towards “5” if fabric edge curls while sewing.(
Fig.1)
Turn it toward “7” if loops hang off the edge. (Fig.2)
Stitch finger (B)
Loops may hang off the edge, when you sew with lightweight fabric using 3 threads (right needle only),
and setting cutting width dial at 4-5(Fig.3). In such a case change the stitch finger(A) to (B) to get neat
stitching(Fig.4)
Cross section
Stitch finger(B)
1
2
