1. KNOWING YOUR MACHINE
IDENTIFICATION CHART
1. Foot pressure regulator
2. Thread cutter
3. Presser foot lever
4. LED lamp
5. Needle plate
6. Presser foot
7. Overedge cutting width dial
8. Working table
9. Thread guide pole
10. Left needle thread tension control
11. Right needle thread tension control
12. Upper Looper thread tension control
13. Lower looper thread tension control
14. Needle thread guides
15. Two thread convertor instruction
16. Threading chart
17. Lint tray
18. Foot control
19. Release lever
20. Foot release lever
21. Spool disc
22. Differential feed control dial
23. Stitch length dial
24. Hand wheel
25. Plug connector socket
26. Light and power switch
27. Front cover
28. Moving cutter
29. Lower looper
30. Upper looper
31. Cord guide
19
21
20
22
23
27
25
24
26
29
28
30
17
18
6
1
2
3
4
5
7
11
31
9
13
8
12
10
14
15
16
