VERITAS NetBackup 5240 Appliance Product Description

Figure 1-1
NetBackup 5240 Appliance front panel disk slot assignments
0
1
2
3
4
5
6
7
8
9
10
11
Table 1-2
NetBackup 5240 Appliance front panel disk drive configurations
Disk drive roleDisk drive sizeRAID
Configuration
Slot
Boot / swap1TBRAID 10, 1
Log files1TBRAID 12, 3
User data6TB3TB1TBDisk drive sizeRAID 64 - 10
27TB14TB4TBAvailable
internal storage
space
Hot spareRAID 611
NetBackup 5240 Appliance disk drive LEDs
Each disk drive module contains two LEDs on the left-hand side of each module.
The LEDs appear as follows:
Figure 1-2
NetBackup 5240 Appliance disk drive module LEDs
Amber Status LED
Green Activity LED
Table 1-3
NetBackup 5240 Appliance disk drive LEDs
IndicationColorDescriptionNumber
No faults
Disk fault
RAID rebuild is in progress
Not lit
Solid amber
Blinking amber
Status LED1
11About the NetBackup 5240 Appliance
NetBackup 5240 Appliance front panel disk drive configurations
