VERITAS NetBackup 5240 Appliance Product Description

the appliance. You can use standard grounding practices to connect grounding
wires to the studs.
The serial number is located on a vertical bar on the rear panel of the appliance.
Figure 1-8
Serial number location
The ports on the rear panel are color-coded for easy identification.
Figure 1-9
NetBackup 5240 Appliance rear port color codes
ETH4/
NIC5
ETH1/
NIC2
ETH0/
NIC1
IPMI
ETH5/
NIC6
ETH2/
NIC3
ETH3/
NIC4
NetBackup 5240 Appliance I/O configuration options
The rear panel of the NetBackup 5240 Appliance contains three PCIe riser card
assemblies. PCIe riser card assemblies 1 and 2 each support three standard PCIe
cards, while PCIe riser card assembly 3 supports two low profile PCIe cards. The
slots are labeled 1 to 8. Slots 1, 2, and 3 are located in PCIe riser card assembly
2. Slots 4, 5, and 6 are located in PCIe riser card assembly 1, while slots 7 and 8
are located in PCIe riser card assembly 3.
20About the NetBackup 5240 Appliance
NetBackup 5240 Appliance rear panel
